Mazda 626 & MX6 GE Wiring Diagrams 11/1995 on Factory Supplement

Factory Publication

By Mazda Staff
— or —

Availability: Usually dispatched same or next day

Ask us a question about this product

Front Cover
Stock image only. Actual cover art may differ.
Mazda 626 GE & MX-6 GE 11/1995 on Factory Wiring Diagram Supplement covers GE series 626 and MX-6 from November 1995 production (MY1996).

Model Numbers:
● JM0 GE20L2
● JM0 GE10S2
● JM0 GE10L2

● Ground Points
● Electrical
● System Circuit Diagram / Connector Locations
● Common Conectors
● Joint Box / Complete Wiring System
● Parts Index

Factory Publication.

Printed in Australia under licence with Copyright to Mazda.

Other titles in this set...

General information on Repair Manuals

Please note that workshop manuals are usually written for models sold in a specific country. Differences in specification can exist between models sold in different countries and items such as engines can vary. Please check that the manual will cover your model before purchase and if you are unsure please contact us first.

Factory repair manuals are the same manuals as those used by the dealers. As they are primarily intended for dealer use the manufacturers usually release a base repair manual when a new model is introduced (either a single manual, multi-volume set or separate volumes) and then release supplementary manuals as the model changes, for example a model facelift or introduction of a new engine. Supplements generally cover only changes to the model and are intended to be used in conjunction with the base repair manual(s). For full coverage you will need the base repair manual and all relevant supplements up to the date your model was manufactured.
