Nissan Model W40 Series (Civilian) Service Manual Supplement 4 (1990)

Factory Publication

By Nissan Staff
— or —
Availability: Usually dispatched same or next day

Or call (02) 9057 4158 to order.
Quote order code NISM1EW40SA0.

Ask us a question about this product

Front Cover
Rear Cover
Stock image only. Actual cover art may differ.
Nissan Model W40 Series (Civilian) Service Manual Supplement 4 (1990) covers VIN/chassis numbers starting from JN10RGW40A0050001 and JN10RYW40A0050001. The model changes covered include change from ED33 engine to TD42 engine, addition of air suspension to Australian models, and addition of auto cooler to Australian models.

Supplement to the factory repair manual for the Nissan Civilian from March 1990.

● General Information
● Maintenance
● Engine Mechanical
● Engine Lubrication & Cooling Systems
● Engine Fuel (including VE-type injection pump)
● Engine Removal & Installation
● Clutch
● Manual Transmission (RS5R50A)
● Front Axle & Front Suspension (including air suspension)
● Rear Axle & Rear Suspension
● Brake System
● Steering System
● Body
● Heater & Air Conditioner ans full wiring for the air-con system too
● Electrical System

Factory Publication.

Printed in Australia under licence with Copyright to Nissan.

DOES NOT include sections on emission control system; engine control, fuel and exhaust systems; and propeller shaft and differential carrier. These are covered in earlier manuals.

This manual is a supplement only and is intended to be used in conjunction with the following manuals for full coverage for models released March 1990:

Nissan Civilian W40 Repair Supplement 1 (out of print)

Other titles in this set...

General information on Repair Manuals

Please note that workshop manuals are usually written for models sold in a specific country. Differences in specification can exist between models sold in different countries and items such as engines can vary. Please check that the manual will cover your model before purchase and if you are unsure please contact us first.

Factory repair manuals are the same manuals as those used by the dealers. As they are primarily intended for dealer use the manufacturers usually release a base repair manual when a new model is introduced (either a single manual, multi-volume set or separate volumes) and then release supplementary manuals as the model changes, for example a model facelift or introduction of a new engine. Supplements generally cover only changes to the model and are intended to be used in conjunction with the base repair manual(s). For full coverage you will need the base repair manual and all relevant supplements up to the date your model was manufactured.
