Nissan Model FD33T Diesel Engine Service Manual Supplement

Factory Publication

By Nissan Staff
— or —
Availability: Usually dispatched same or next day

Or call (02) 9057 4158 to order.
Quote order code NISM3EFD33G0.

Ask us a question about this product

Front Cover
Stock image only. Actual cover art may differ.
Nissan Model FD33T Diesel Engine Service Manual Supplement covers the Nissan FD33T diesel engine as used in Nissan Cabstar (H40) and Civilian (W40), from June 1983.

The manual includes procedures for maintenance, adjustments, removal and installation, disassembly and assembly of components, and trouble-shooting.


General Information
● Specifications
● Engine serial number location
● Tightening torque of standard bolt

● Basic Mechanical System
● Injection and fuel system
● Cooling and lubrication system
● Service data and specifications
● Trouble diagnosis and corrections

Engine mechanical
● Engine components
● Engine disassembly
● Inspection and repair
● Engine assembly
● Service data and specifications
● Special service tools

Engine lubrication & cooling systems
● Engine lubrication system
● Engine cooling system
● Service data and specifications

Engine fuel
● Injection pump assembly
● In-line pump
● Injection nozzle assembly
● Turbocharger

Factory Publication.

Printed in Australia under licence with Copyright to Nissan.

The harmonic Balancer socket size is 55mm. Some customers have been trying to find this measurement. Thanks.

Other titles in this set...

General information on Repair Manuals

Please note that workshop manuals are usually written for models sold in a specific country. Differences in specification can exist between models sold in different countries and items such as engines can vary. Please check that the manual will cover your model before purchase and if you are unsure please contact us first.

Factory repair manuals are the same manuals as those used by the dealers. As they are primarily intended for dealer use the manufacturers usually release a base repair manual when a new model is introduced (either a single manual, multi-volume set or separate volumes) and then release supplementary manuals as the model changes, for example a model facelift or introduction of a new engine. Supplements generally cover only changes to the model and are intended to be used in conjunction with the base repair manual(s). For full coverage you will need the base repair manual and all relevant supplements up to the date your model was manufactured.

Nissan Motor Company (Japan)
